• Accepts 5/16" (M8) ring terminals
  • For use on systems up to 32 Volts DC
  • Swing out design allows replacement of the fuse without removing fasteners
  • Stainless steel studs provide resistance to corrosion and high torquing for excellent electrical contact
  • UL 94-V0 base resists high heat
  • Insert molded studs ensure secure fuse mounting
  • Insulating cover satisfies ABYC/USCG requirements
  • Cover breakouts allow wire access in any direction
  • Fuse sold separately
Maximum Voltage 32V DC
Maximum Amperage 300A
Base Material Reinforced Polycarbonate
Fuse Mounting Blocks Tin-Plated Copper
Maximum Cable Size 2/0 AWG
Maximum Torque 110 in-lb (12.43 Nm)
Terminal Stud Size 5/16" - 18 (M8)
Weight 0.35lb (0.16 kg)



SKU BSS5005B
Barcode # 5005-BSS
Brand Blue Sea Systems
Shipping Weight 0.2000kg
Shipping Width 0.200m
Shipping Height 0.050m
Shipping Length 0.100m
Shipping Cubic 0.001000000m3
