Closed back design completely insulates power from the mounting surface

Each screw pair is one isolated circuit

Jumpers allow creation of common circuits

Circuits 8
Maximum Voltage 300V AC/DC
Continuous Rating 65A
Base Material UL 94-V0 Rated, Glass Reinforced Thermoplastics
Bus Material Nickel-Plated Brass
Screw Material Stainless Steel
Terminal Screws M5
Screw Terminal Torque 7 in-lb (0.79 Nm)
Weight 0.43b (0.2 kg)





SKU 632085026080
Barcode # 2608-BSS
Brand Blue Sea Systems
Shipping Weight 0.2200kg
Shipping Width 0.205m
Shipping Height 0.030m
Shipping Length 0.070m
Shipping Cubic 0.000430500m3
