Provides convenient busing for limited space applications

  • Easily add positive and negative busbars directly to a threaded-post battery terminal
  • Tin-plated pure electrical copper for maximum conductivity
  • Insulating covers meet ABYC/USCG insulation requirements
  • Screw terminals for securing wires
  • Includes four 16-14 AWG and four 12-10 AWG Nylon insulated ring terminals
  • CE Certified
Maximum Voltage 300V AC / 48V DC
Continuous Rating 100A
Number of Screw Terminals 4
Terminal Stud 1 x #10-32
Terminal Type #8-32 Screws
Bus Material Tin-Plated Copper CDA 110/ UNS11000
Mounting Hole Clearance for Ø3/8 [M10] stud
Wire Size (1) 8 AWG to 4 AWG - Input
(4) 16 AWG to 10 AWG - Load



SKU 632085023560
Barcode # 2356-BSS
Brand Blue Sea Systems
Shipping Weight 0.3000kg
Shipping Width 0.200m
Shipping Height 0.060m
Shipping Length 0.210m
Shipping Cubic 0.002520000m3
