2.5mm (12AWG) Elflex 2 Core Tinned Flexible Rubber Cable 27 Amp 2.5mm² - Sold per Meter
2.5mm (12AWG) 2 Core Tinned Rubber Cable 27 Amp 2.5mm²
Elcon Cables is one of Australia's largest privately owned cable distribution companies.
With over 25 years in cable manufacturing, providing exceptional service at competitive prices they supply bot quality Australian-Made cables as well as the best from overseas.
FMR Heavy Duty Multi Core Rubber Insulated and Sheathed Flexible Power Cables
Features: Submersible to 200mtrs | Suitable for fresh water, salt water, sewage/contaminated water | UV, Sunlight, oil and weather resistant | Flame retardant to IEC 60332-1-2:2004, EN60332-1-2-2004 | Temperature range -25°C to +90°C | Maximum permisible short circuit temperature 1s 250°C
- APPLICATIONS: Submersible pumps, limit switches, Wet or oily environments, Mine sites and quarries
- CONDUCTOR: Class 5 tinned copper according to AS/NZS 1125, IEC 60228
- INSULATION: Ethylene-propolene rubber (EPR) R-EP-90 90˚C Conducto
- INNER SHEATH: EPDM Rubber (200m)
- OUTER SHEATH: Chlorinated Polyethylene, CPE rubber compound
- VOLTAGE: 0.6/1kV
- SHEATH COLOUR: Black
- PACK: Cut to length, other packs by request
CORE COLOUR:
- 2 Core: Blue, Brown
- 3 Core: Green/Yellow, Blue, Brown
- 4 Core: Green/Yellow, Brown, Black, Grey
- 5 Core: Red, White, Blue, Black & Green/Yellow
- 7 Core: Green/Yellow, other Cores Black with White Numbering
- 12 Core: Green/Yellow, other Cores Black with White Numbering
| Elcon Code | FMR2x2.5 |
|---|---|
| Nearest AWG | 12 AWG |
| Nominal Area (mm²) | 2.5mm |
| **AMP Rating @ 30°C | 27 A |
| Insulation Thickness V90HT (mm) | 1.7mm |
| Electrical Resistance @ 20°C (ohm/km) | 8.21Ω |
| Nominal O.D. (mm) | 11.0mm |
| Mass (kg/100m) | 18.2kg |
* MM is an industry term that identifies cable size and is not CONDUCTOR CROSS SECTION AREA
** AMP RATING: TO JASO D609 de rating factors apply
De-Rating Factors for Bundling of Single Core Cables
| No. Of Cables | 1 | 2 | 3 | 4 | 5 | 6 | 7 or 8 | 9 or 10 |
|---|---|---|---|---|---|---|---|---|
| De-Rating Factor | 1.00 | 0.80 | 0.70 | 0.60 | 0.55 | 0.5 | 0.45 | 0.4 |
De-Rating Factors for Ambient Temperatures °C
| No. Of Cables | 30°c | 40°c | 50°c | 60°c | 70°c |
|---|---|---|---|---|---|
| De-Rating Factor | 1.00 | 0.90 | 0.76 | 0.60 | 0.45 |
| SKU | CAFMR2x2.5 |
| Brand | Elcon Cables |
| Shipping Width | 0.150m |
| Shipping Height | 0.025m |
| Shipping Length | 0.150m |
| Shipping Cubic | 0.000562500m3 |
